Features:
- Programmable PWM Digital Amplifier
- 4096 Resolution
- 1M Cycle Long Life Potentiometer
- Wide Operating Voltage (4.8 ~ 8.4 Volts DC)
- Dual Ball Bearing Supported Output Shaft
- 32-Bit MCU with 12-Bit ADC Circuitry
- 8.4 Volts DC
- Dual Ball Bearing Supported Output Shaft
- 25-Tooth Output Spline
- Coreless Metal Brush Motors
- Nylon Reinforced Plastic Upper and Lower Case
- Diamond Cut Aluminum Heat Sink Center Case
- Dust Resistant and Splash Proof Case
- End Point Adjustment
- Direction
- Fail Safe
- Dead Band
- Speed (Slower)
- Soft Start Rate
- Overload Protection
- Data Save / Load
- Program Reset
Performance Specifications Operating Voltage Range (Volts DC) 4.8V ~ 7.4V Speed (Second @ 60°) 0.19 ~ 0.12 Maximum Torque Range oz. / in. 251 ~ 404 Maximum Torque Range kg. / cm. 18.0 ~ 29.0 Current Draw at Idle 30 mA No Load Operating Current Draw 500 mA Stall Current Draw 5,200 mA Dead Band Width 1µs Physical Specifications Dimensions (Inches) 1.57 x 0.78 x 1.46 Dimensions (Metric) 40.0 x 20.0 x 37.0 Weight (Ounces) 2.33 Weight (Gram) 66.0 Circuit Type 32bit Programable Digital Motor Type Coreless Metal Brush Gear Material MK 1st Gear & 3 Titanium Gears Bearing Type Dual Ball Bearing Output Shaft (type / mm) H25T Case Material Plastic / Aluminum Dust / Water Resistance Splash Proof Connector Gauge (AWG) / Strand Count 20 / 80 Radio Control Applications Parkflyer N / A Sport Plane 30 - 40% Sailplane 2 meters and up 3D Performance 30 - 40% Scale 30 - 40% Electric Helicopter N / A Gas Helicopter N / A On Road 1/8th Monster Truck 1/8th Buggies 1/8th Truggies 1/8th Short Course / Truck 1/8th Crawlers 1/8th Sail Boat = >1M & Scale Power Boat N/A
