Maytech 8085 160KV 250KV Brushless Outrunner Sensorless Motor for RC airplanes / Electric Skateboard / Fighting Robots
| Model No | MTO8085-250-G | MTO8085-160-G | |
| KV | 250 | 160 | |
| Shaft Diameter | 12mm | 12mm | |
| Max. Current | 116A | 123A | |
| Input Volt. | 6-14S | 6-14S | |
| Net Weight(g) | 1180 | 1180 | |
| Stator Size (mm) | φ68.0x30 | φ68.0x30 | |
| Motor Size (mm) | φ80.0x74 | φ80.0x74 | |
| WATT. | 5820W | 6150W | |
Application: Rc Airplane/RC Helicopter/RC Plane/Electric skateboard/Longboard/E-bike/E-scooter/Motorcycle/Fighting robots/Combat robots/Motorized mountainboard/All terrain offroad skateboard/Esk8
Motor Drawing:
Recommend ESC:
